| Brand Name: | SWIFT |
| Model Number: | SWT25100HC |
| MOQ: | 1pcs |
| Price: | Negotiation |
| Delivery Time: | 10 -15days |
| Payment Terms: | T/T |
1.0S Zip Tie Tool Quick Fast Bundle Cable Tie Gun For Air Bag Harness
Using SWT25100HC cable tie machine to bundle automaticaly, it is fastet 2-3 times than manual binding.
Features of automatic zip tie tool gun
1 . It is small and convinient to put on the worktable. It wouldn't take much space.
2. It is available for reel cable ties C25100 but cable tie gun can bundle different sizes of air bag wire harness, such as 3-18mm.
3. Smart cable tie gun: automatically detecting cable tie jam and restart.
4. The temperature controlling system protects the cable ties from get fragile in cold winter.
5. It is easy to collect the waste materials after finishing bundle.
6. Once pulliing the trigger of tie gun, nylon plastic cable ties will be wrapped, tightened ang cut.
Product parameters of handheld cable tie gun
| NO | Item | Description | Value |
| 1 | Model | SWT25100HC | No |
| Handheld type available | No | ||
| 2 |
Size Of cable size ( reel cable ties) |
Width | 2.5mm |
| Length | 100mm | ||
| Thicker | 1.15mm | ||
| 3 | Operation speed | For one cable tie | 1.0S |
| 4 |
Max banding Dia.
|
For wire | Ø 18.0mm |
| For tube | Ø 16.0mm | ||
| 5 | Min banding Dia. | For tube / wire | Ø 3.0mm |
| 6 | The feeding hose | Length | 1.5-2.2m |
| 7 | The bending force | Adjustable, ,max 80N | |
| 8 | Voltage | AC220V, 50 / 60Hz | |
| Different plugs | |||
| 9 | The gun V. | DC24V (switch automatically) | |
| 10 | Power | 1KW | |
| 11 | Pneumatic pressure | 5kg / cm² | |
| 12 | Warranty | 12monthes | |
| Tech support forever | |||
Product details of nylon cable tie machines
1. Using famous electric parts, like Omron PLC, SMC. SWT25100HC auto cable tie system has longer life.
2. Machine structure is made of stailess steel, not plastic. It is durable.
FAQ
1. How could I get the quotations?
Pls inform us by email. Our factory mainly produces automatic cable tie machines and nylon zip ties. There are too many types. It is better if you could inform us what you looking for.
2. Do you provide design services?
Yes, we do.
3. What is the warranty?
12months.
