5M2210ZF324C5N IC CPLD 1700MC 7NS 324FBGA I/O 271 Macrocells 1700
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Embedded | |
| CPLDs (Complex Programmable Logic Devices) | |
| Manufacturer | Intel |
| Series | MAX® V |
| Packaging | Tray |
| Programmable Type | In System Programmable |
| Delay Time tpd(1) Max | 7 ns |
| Voltage Supply - Internal | 1.71V ~ 1.89V |
| Number of Logic Elements/Blocks | 2210 |
| Number of Macrocells | 1700 |
| Number of I/O | 271 |
| Operating Temperature | 0°C ~ 85°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 324-LBGA |
| Supplier Device Package | 324-FBGA (19x19) |
| Base Product Number | 5M2210Z |
Features of 5M2210ZF324C5N
■ Low-cost, low-power, and non-volatile CPLD architecture
■ Instant-on (0.5 ms or less) configuration time
■ Standby current as low as 25 μA and fast power- down/ reset operation
■ Fast propagation delay and clock-to-output times
■ Internal oscillator
■ Emulated RSDS output support with a data rate of up to 200 Mbps
■ Emulated LVDS output support with a data rate of up to 304 Mbps
■ Four global clocks with two clocks available per logic array block (LAB)
■ User flash memory block up to 8 Kbits for non-volatile storage with up to 1000 read/ write cycles
■ Single 18-V external supply for device core
■ MultiVolt I/O interface supporting 3.3-V, 2.5-V, 1.8-V, 1.5-V, and 1.2-V logic levels
■ Bus- friendly architecture including programmable slew rate, drive strength, bus-hold, and programmable pull-up resistors
■ Schmitt triggers enabling noise tolerant inputs (programmable per pin)
Applications of 5M2210ZF324C5N
■ I/Os are fully compliant with the PCI-SIGD PCI Local Bus Specification, revision 2.2 for 3.3-V operation
■ Hot-socket compliant
■ Built-in JTAG BST circuitry compliant with IEEE Std.1149.1-1990
Environmental & Export Classifications of 5M2210ZF324C5N
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | RoHS Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | 3A991D |
| HTSUS | 8542.39.0001 |
|
|
