Camouflage Nettings 40pcs/Min 1.0S Automatic Cable Tie Gun
40pcs/min 5,000pcs reel cable ties for automatic cable tie gun
1. SWT25100HC only uses cable ties in reel and has a handheld cable tie gun.
2. 5,000pcs nylon zip ties in reel.
3. Bundle capacity: 2,400 - 3,000pcs/hour
Features of automatic cable tie machine
1. Automatic cable tie machine SWT25100HC is smallest without feeder bowl.
2. There is a handheld cable tie gun. It is convenient to use the tie gun.
3. There are 5,000pcs cable ties in reel. After installs it in the cable tie machine, operator doesn’t need to put cable ties very often.
4. Handheld tie gun is light, the weight is 0.86kg. And it is comfortable to hold and operate.
5. After cable ties are cut off, the waste can be collected into a box through a transparent tube.
6. If there is any cable ties jammed in the hose or tie gun, the automatic cable tie machine would automatically stop running and clean them, then restart.
7. The tie gun needs air source supply and asks 5kg/cm²
Specifications of automatic cable tie machine
| Model | SWT25100HC |
| Applicant cable ties | C25100 |
| Cable tie size | W2.5 * L100mm * T1.1mm |
| Cable ties material | Nylon PA6.6 |
| Min binding Dia. | Ø3 mm |
| Max banding dia. | Ø18 mm |
| Operation speed | 1.0s/cable tie |
| Electrical power | Host: AC 220V, 50/60 Hz, different plugs |
| Tool tie gun: DC24V(automatic switching) | |
| Pneumatic pressure | 5 Kg/ cm² |
| Power | 1KW |
| Maximum tension force | 80N, adjustable |
| Productivity | 2,400 – 3,000 pcs/h |
| Weight | Host:30 kg |
| Handheld tie gun: 0.86kg | |
| Size | Host: L710 * 470 * 230mm |
| Gun: L250 * W102 * H64mm | |
| Certificate | CE & RoHS for automatic cable tie machine |
| REACH, RoHS for nylon cable ties | |
| Machine shell | The stainless steel(Customize) |
| Structural steel(Standard) |
Application of automatic cable tie equipment
1. Wire harness in the board, wire harness in the home appliance.
2. Bags sealed
3. Camouflage nettings
Advantages of handheld cable tie gun
1. Once operator touches the trigger, cable tie gun can automatically bundle nylon cable ties, including wrapping, pulling and tightening, cutting off.
2. The bundle capacity is 2,400 – 3,000pcs in a hour. It is faster than manual bundling.
3. The bundle forces are adjustable. The max is 80N.
4. There is no vibration bowl. The noise is lower.
About packing
Be packed in wooden case.
| Item | QTY | Packing size | G.W./kg | N.W./kg |
| SWT25100HC/wooden case | 1pcs | 60*57*60cm | 41kg | 31kg |
| C25100 reel cable ties/carton box | 10,000pcs | 47*47*30cm | 7kg | 5.4kg |
About delivery
Lead time for machine: 12working days. If you are urgent, please contact sales team.
Large quantities will be executed based on the contract.
FAQ
1. Do you have the smaller automatic cable tie machine than SWT25100HC?
No, it is the smallest one.
2. Do you have such a cable tie gun that can deal with special nylon cable ties, like auto clips?
No, we are developing these tie guns. Now, automatic cable tie machines in our factory deal with general nylon cable ties. And it asks good nylon zip ties.
3. Could I ask for stainless steel shell of auto cable tie machine?
Yes, please tell the sales man if you need stainless steel.
