Multi Function Bundle Forces 20N Automatic Wire Tie Machine

Multi Function Bundle Forces 20N Automatic Wire Tie Machine

  • High Light

    20N Automatic Wire Tie Machine

    ,

    20N Auto Wire Tie Machine

    ,

    80N Auto Wire Tie Machine

  • Bundle Dia.
    2mm - 18mm
  • Bundle Productivity
    1800pcs/h(including Auxiliary Time)
  • Bundle Speed
    0.7S
  • Bundle Forces
    20N-80N
  • Applicant Cable Ties
    W2.5mm * L100mm *T1.1mm
  • Cable Ties Model
    T25100, Loose General Nylon Cable Ties
  • Voltage
    AC220V,50/60Hz
  • Pneumatic Pressure
    5kg/cm2
  • Place of Origin
    Shenzhen, China
  • Brand Name
    SWIFT
  • Certification
    CE, RoHS
  • Model Number
    SWT25100H
  • Minimum Order Quantity
    1pcs
  • Price
    negotiation
  • Packaging Details
    wooden cases
  • Delivery Time
    10 -15days
  • Payment Terms
    T/T
  • Supply Ability
    100pcs/month

Multi Function Bundle Forces 20N Automatic Wire Tie Machine

Multi Function Bundle Forces 20N Automatic Wire Tie Machine



Automatic cable tie gun spends 0.7 second in wrapping, tightening and cutting nylon cable ties, and collecting the waste into a plastic box.



Features of automatic cable tie gun



1. The auto cable tie gun asks for good nylon cable ties.



2. Ergonomic hand shank design, comfortable to hold and operate.



3. Use loose nylon cable ties.



4. The binding forces are adjustable from 2kg to 8kg.



5. Once operator pulls the trigger of the tie gun, nylon cable tie would be bundled.



6. Nylon cable ties are put into the vibration bowl by hand.



7. The handheld tie gun can be applied to full automation line.



Technical data of nylon cable tie machine



Model SWT25100H Bundle speed 0.7S/pcs
Applicant cable tie model T25100 Bundle productivity 1800pcs/h(Including auxiliary time)
Applicant cable tie size W2.5 * L100 * T1.1mm Power 1,000W
Bundle diameter for wire harness 2mm – 18mm Voltage AC220V, 50/60Hz
Bundle diameter for tube 2mm – 16mm Pneumatic pressure 5kg/cm²



Application of automatic cable tie gun



1. Medical industry Bags sealed, silicone tubes and connectors fixed
2. Home appliance On-site assembly of internal wire harness of oven, air conditioners
3. Military industry Camouflage net/netting



Advantages of automatic cable tie machine



1. Our factory has 50 patents of automatic cable tie guns and nylon cable ties.



2. We have developed and produced automatic cable tie machines over 8years.



3. More than 400 clients are using our automatic cable tie guns.



4. There are handheld cable tie guns, fixed tie wrap guns, desktop cable tie machines, full-automatic cable tie guns with robots in our factory. Users can select one based on their different products.



5. Stable quality and long working-life: all cable tie guns are made from alloy steel, structure steel and electric components from well-known brand.



6. Our factory uses good raw material PA66 to produce nylon cable ties.



About packing



NO The host and others The bowl Nylon cable ties T25100
Package Wooden case Wooden case Carton box
Qty 1pcs 1pcs 1pcs
Packing size 80*80*90cm 70*60*70cm 54*37*29cm
G.W./kg 100kg 77kg 15kg
N.W./kg 74kg 60kg 14kg
Picture Multi Function Bundle Forces 20N Automatic Wire Tie Machine 0 Multi Function Bundle Forces 20N Automatic Wire Tie Machine 1 Multi Function Bundle Forces 20N Automatic Wire Tie Machine 2



About delivery



1. Lead time for nylon cable tie machine: 10-15workign days



2. Lead time for nylon cable ties: 10days



3. Automatic cable tie machine can be shipped by air, or by sea.



FAQ



Questions Answers
1. Do you have service centers in other countries?

1. No, we haven’t. But we have clients who are form USA, Mexico, Brazil, UK and Italy etc.

2. Where is your factory? 2. In Shenzhen China. Warmly welcome to visit us.
3. Do you have English manual? 3. Yes, all machines have English manuals.
4. How do I adjust the binding force? 4. There is a knob to spin In the cable tie gun. And there is a small window to display the force value.
