0.5Mpa Handheld Automatic Cable Tie Tool For Wire Harness Assembly

0.5Mpa Handheld Automatic Cable Tie Tool For Wire Harness Assembly

  • High Light

    0.5Mpa Automatic Cable Tie Tool

    ,

    AC220V Automatic Cable Tie Tool

    ,

    0.5Mpa cable tie installation tool

  • Product Name
    Automatic Cable Tie Gun
  • Cable Ties Reel
    W2.5 * L100mm, 5,000pcs/reel
  • Bundling Dia.
    Ø3mm - Ø17mm
  • Bundle Forces
    20-80N Adjustable
  • Bundle Speed
    1.1S
  • Voltage
    AC220V, 50/60Hz
  • Place of Origin
    Shenzhen, China
  • Brand Name
    SWIFT
  • Certification
    CE
  • Model Number
    SWT25100HC
  • Minimum Order Quantity
    1pcs
  • Price
    Negotiation
  • Packaging Details
    wooden case
  • Delivery Time
    10 - 15days
  • Payment Terms
    T/T
  • Supply Ability
    100pcs/month

0.5Mpa Handheld Automatic Cable Tie Tool For Wire Harness Assembly

0.5Mpa Handheld Automatic Cable Tie Tool For Wire Harness Assembly​



Handheld Nylon Cable Tensioning Tools For Wire Harness Assembly 80N forces Adjuste



Electric bundling machine for nylon cable ties.



No lost time for cleaning the waste boxes.



Excellent performance, bundle speed up to 1.1S.



Advantages of automatic cable tie system



1. It is the smalles automatic cable tie machine, the gross weight is about 30KG.



2. Using cable ties reel, C25100, 5,000pcs/reel.



3. The bundle speed is up to 1.1seconds.



4. The binding forces are adjustable from 20N to 80N. Different numbers means different forces.



5. The handheld cable tie gun is slight, o.86kg and is easy and comfortable to hold.



6. The waste materials are collected into a box automatically so that it is easy to clean them.



7. Under max bundle diameter, the machine adapts to bind the different sizes wire harness.



8. The bundle diameters: 2mm - 17mm



Technical parameter of electric nylon cable tie gun



Model SWT25100HC
Description Automatic cable tie tool
Application Automatically binding objects with cable ties - tightly and quickly.
Cable tie spec W2.5 * L100mm(standard), C25100
Cable tie features Straight without deformation, no tilt angle, tensile strength 14kg
Cable ties quantity 5,000pcs/reel
Min bundle diameter Ø3.0mm
Max bundle diameter for wire Ø17mm
Max bundle diameter for tube Ø16mm
The bundle speed 1.0S
Host machine size L710 * W470 * H230mm
Cable tie gun size L250 * W102 * H64mm
Electric power AC220V – AC240V, 50/60Hz



Applications



suitable for binding wire harness of airplane, train, ship, automobiles, communication equipment, home appliances and other large electromechanical equipment, etc. Also , applicable to packing and fixing of other products, such as food packing, gas & liquid transporting tube connector, etc.



0.5Mpa Handheld Automatic Cable Tie Tool For Wire Harness Assembly 0



The assembly room



0.5Mpa Handheld Automatic Cable Tie Tool For Wire Harness Assembly 1
