80mm Length Zip Tie Easy Bundle 3000pcs Of Automatic Cable Tie Gun

80mm Length Zip Tie Easy Bundle 3000pcs Of Automatic Cable Tie Gun

  • Bundle Productivity
    3000pcs/h
  • Bundle Dia.
    Ø2mm - Ø14mm
  • Cable Ties Size
    W2.5mm * L80mm *T1.1mm
  • Cable Tie Material
    Nylon PA 6.6
  • Bundle Speed
    0.7S(Not Including Auxiliary Time)
  • Bundle Forces
    20N - 80N Adjustable(5forces)
  • Voltage
    AC220V - AC240V, 50/60Hz
  • Pneumatic Pressure
    5kg/cm²
  • Place of Origin
    Shenzhen, China
  • Brand Name
    SWIFT
  • Certification
    CE, RoHS
  • Model Number
    SWT25080H
  • Minimum Order Quantity
    1pcs
  • Price
    Negotiation
  • Packaging Details
    Wooden cases
  • Delivery Time
    12 - 15days
  • Payment Terms
    T/T
  • Supply Ability
    100pcs/month

80mm Length Zip Tie Easy Bundle 3000pcs Of Automatic Cable Tie Gun

80mm Length Zip Tie Easy Bundle 3000pcs Of Automatic Cable Tie Gun



Electric handheld cable tie gun for 80mm length nylon tie wraps is the smallest tie gun in the world.



Features of automatic cable tie machine



1. Using the smallest nylon cable ties T25080, width 2.5mm * length 80mm



2. Automatic cable tie machine can only deal with specific cable ties.



3. Electric cable tie gun can adapt to bundle your products’ diameters from 2mm to 14mm.



4. Operator can easily adjust the binding forces by turning a knob in the tie gun.



5. Automatic cable tie gun takes only 0.7S to wrap, tighten and cut off nylon cable tie.



6. The waste material would be collected into a box.



7. Pneumatic pressure 5kg/cm² and voltage AC220V, 50/60Hz



Specification of nylon cable tie machine



Model SWT25080H
Cable ties model T25080
Cable tie size W2.5mm * L80mm * T1.1mm
Cable ties material Nylon PA 6.6
Min banding Dia. Ø2 mm
Max banding dia. ø14 mm
Operation speed 0.7s/cable tie
Electrical power Host machine: AC 220V, 50/60 Hz
Handheld tie gun: DC 24V(automatic switching)
Pneumatic pressure 5 Kg/ cm²
Power 1,000W
Maximum tension force 80 N(20-80N adjustable)
Productivity 3,000pcs/h(including auxiliary time of picking products up and putting them down)
Weight Host machine:140 kg, with 4 wheels
Handheld tie gun: 0.84kg
Certificate CE & RoHS



80mm Length Zip Tie Easy Bundle 3000pcs Of Automatic Cable Tie Gun 0



Application of automatic cable tie machine



1. Crafts: knee pads, lighting accessories



2. Wire harness in tooling plate: cable tie gun can bundle wire harness by nylon cable ties easily and quickly.



3. Camouflage net/nettings



Advantage of automatic cable tie gun



1. Professional design team



Our factory devotes to developing automatic cable tie gun over 8 years and would like to provide suitable equipment solution for you.



2. Quality first.



Excellent factory management and experienced production team are excellent quality important guarantee.



3. Efficient team, 7*16h service.



About packing



Automatic cable tie machine would be packed in wooden cases.



Item Packing size G.W. N.W.
Host machine for SWT25080H L74 * W69 * H84cm 97kg 75kg
Vibration bowl for SWT25080H L53 * W49 * H51cm 67kg 55kg



About delivery



1. Lead time: 10-15working days



2. It is no problem to ship by air/FedEx/TNT/DHL



3. Certificates: CE, RoHS, REACH



FAQ



1. Can this automated tool use different size cable ties?



No, it can’t. Automatic cable tie machine SWT25080H can use nylon cable tie T25080.



2. Do you have a cable tie gun that could work with two different cable ties?

No, we don’t have such an automatic cable tie machine.



3. Can only a cable tie gun work?



No, the cable tie gun must work together with the host machine.
