Fast Lock Nylon Zip Ties Automatic Cable Tie Gun For Christmas Lamp Theme

Fast Lock Nylon Zip Ties Automatic Cable Tie Gun For Christmas Lamp Theme

  • High Light

    automatic cable tie machine

    ,

    auto bundling machine

  • Product Name
    Automatic Cable Tie Tool
  • Model
    SWT25120H
  • Cable Tie Size
    W2.5 * L120mm
  • Min Binding Dia.
    Ø2.0mm
  • Max Binding Dia.
    Ø22mm
  • Binding Speed
    0.8S
  • Voltage
    AC220V, 50/60Hz
  • Power
    1000W
  • Place of Origin
    China
  • Brand Name
    Swift
  • Certification
    CE
  • Model Number
    SWT25120H
  • Minimum Order Quantity
    1 pcs
  • Price
    negotiation
  • Packaging Details
    wooden cases
  • Delivery Time
    10-15days
  • Payment Terms
    T/T
  • Supply Ability
    100/month

Fast Lock Nylon Zip Ties Automatic Cable Tie Gun For Christmas Lamp Theme

Fast Lock Nylon Zip Ties Automatic Cable Tie Gun For Christmas Lamp Theme



Usually it would use lots of nylon cable ties in Christmas lamp theme. If workers use hands to bundle nylon zip ties, it would take too much time. Now SWIFT produces automatic cable tie guns. They can automatically bundle nylon zip tie in 0.7second. That means it can bundle at least 3,000pcs cable ties.



SWT25120H parameters



Name Automatic cable tie tool, SWT25120H
Components A host machine and a handheld auto cable tie gun
Cable tie specification W2.5mm * L120mm
Cable tie material Nylon 66
Min bundle diameter Ø2mm
Max bundle diameter for wire Ø22mm
Max bundle diameter for tube Ø21mm
The bundle speed 0.8S
Host machine weight 135kg
Handheld auto able tie gun weight 0.86kg
Electric power AC220V, 50/60Hz
Pneumatic pressure 0.5Mpa
Power 1,000W



SWT25120H advantages



1. Automatically bundle nylon zip ties. They are loose and they are made of nylon PA66.



2. You put loose cable ties into the host machine. They would be sorted and lined.



3. You pull the cable tie gun trigger, it automatically wraps, pulls and tightens cable ties, cuts them off and collects the rubbish.



4. After bundling, it is very tightly. 5 binding can be adjusted according to your need.



The cursor scale corresponds to the binding force
Vernier graduate 0 1 2 3
Theory calculation 2kg 4kg 6 kg 8Kg



5. The max binding diameter for wire harness: 22mm. It can be adapted to different sizes wire harness.



6. The machine would alarm and stop working if have problem. You would hear "the alarm".



7.  With the cable tie gun "reset" function. The cable tie machine can automatically detect jammed or not. If jammed, pls pull the trigger longer 2 or 3seconds, the jammed would be dealt and the machine would restart.



8. Bundling speed is up to 0.8 second.



9. Certificates: CE, RoHS



Packing details



Be packed in two wooden cases. G.W.: about 150kg.



Trade terms



1. Lead time: 10 – 15working days.



2. Payment: 100% TT payment before ship.



3. Price: EXW,FOB



FAQ



1. Where is your factory?



Our factory is located in Shenzhen, China. We devote to automatic cable tie guns more than 7years.



2. Does automatic cable tie machine have requires on nylon cable ties?



Yes, it does. Nylon cable ties must be stronger, no deformation, in good shape etc.



3. What is the payment term?



Usually, we agree 100% TT payment before ship.



4. Can you make this machine with a robot?



Yes, we can make it and pls find other products' introductions in the website.



Applications
