18mm Diameter Handheld Automatic Cable Tie Tool Machine SWT25100H CE Certificates

18mm Diameter Handheld Automatic Cable Tie Tool Machine SWT25100H CE Certificates

  • Cable Tie Gun
    Handheld Type
  • Binding Dia.
    Ø2mm - Ø18mm
  • Cable Ties Size
    W2.5mm * L100mm
  • Voltage
    AC220V, 50/60Hz
  • Function
    Auto Wrap, Tighten, Cut Off
  • Place of Origin
    China
  • Brand Name
    SWIFT
  • Certification
    CE
  • Model Number
    SWT25100H
  • Minimum Order Quantity
    1pcs
  • Price
    Negotiation
  • Packaging Details
    wooden case
  • Delivery Time
    12 - 15days
  • Payment Terms
    T/T
  • Supply Ability
    100pcs/month

18mm Diameter Handheld Automatic Cable Tie Tool Machine SWT25100H CE Certificates

18mm Diameter Handheld Automatic Cable Tie Tool Machine SWT25100H CE Certificates



The max binding diameter is 18mm. The machine has a handheld cable tie gun. It could automatically wraps, tightens and cut off nylon zio ties.



Why to use automatic cable tie tool machine?



Because the tool can help you to improve the work efficiency and save money. It takes 0.7S to bundle single cable tie but worker spends 6S by hand. One machine saves 3 workers' cost.



It is more convinient. Once touch the trigger, the cable tie tool starts to bundle automatically.



Specification



Model SWT25100H
Binding speed 0.7S
Binding diameters 2mm - 18mm
Cable ties size W2.5 * L100mm
Cable ties model T25100
Cable ties material Nylon PA66
Cable tie gun type Handheld
Pneumatic pressure 5kg/cm2
Voltage AC220V, 50/60Hz



Advantages



1. Using loose cable ties, T25100, W2.5 * L100mm



2. Handheld cable tie gun is easy to hold. The weight is 0.85kg.



3. Once pull the trigger, the cable tie gun starts to wrap, tighten and cut off cable ties.



4. The waste materials would be collected into a box.



5. There are five binding forces to adjust.



6. Vibration feeding. Just put nylon zip ties into the vibration bowl. They would be transferred in the cable tie gun.



7.  The machine is power and pneumatic machine.



Applications



Save time : Improve the bundle speed. The tool takes 0.7S to bundle single cable tie.



Save cost: Replace 3 workers.



Wire harness of soundbox/audio/desktop audio need to be managed. Gnerally, workers would use nylon cable ties to bundle the harness.



Using automatic cable tie tool, you would find it is fast and convinient.
