Handheld Type Automatic Cable Tie Tool For Condensor Insulating Rubbers
Condensor insulation rubber pipe diameter is less than 21mm. Handheld automatic cable tie gun SWT25120H could automatic install cable ties in the condensors.
Description
1. Cable ties are loose and could be put in the vibration bowl. They would be transferred into the cable tie tool gun.
2. Pulling the trigger, automatically wrap, pull & tighten, cut off, collect the waste material into waste tank.
3. There is a small handheld cable tie gun.
4. With touch screen, easy to manage. English and Chinese language.
5. Binding forces : 2kg, 3.5kg, 5kg,6.5kg,8kg
6. Voltage : AC220V, 50/60Hz
Specifications
| Machine model | SWT25120H |
| Cable ties model | T25120 |
Cable tie spec |
2.5*120mm |
| Min banding Dia. | ø2.0mm |
| Max banding dia. for tube | ø21mm |
| Operation speed | 0.8S |
| Host size & weight | L725* W710* H670mm, Weight: 150kg |
| gun size(L*H*T mm) | 256*108*66 |
| gun weight | 0.86kg |
| Electrical power | Host : AC 220V 50/60 Hz Gun : DC24V Power:1000W |
| Pneumatic pressure | 5 Kg/cm² |
Automatic cable tie bundle machine
1. Vibration bowl: Pls connect with the host machine. Turn on, choose 4 or 5.
2. The handheld cable tie gun: pulling the trigger, starting to lock, tighten and cut off cable ties.
3. The feeding tube: transfer cable ties into cable tie gun
4. Data cable: It connect the handheld cable tie gun and the host machine.
Application
Condensor insulating rubber pipes
FAQ
1. What is your Pre-sales service ?
We will provide you with a selection service based on your sample (tied work-piece or nylon cable tie) or a picture(better video),or an improvement on the field-related process with your company.
2. How to control your product quality?
Our factory certified to ISO 9001-2015 quality management system. We control products quality in strict according to this standard. All products are CE certified and have passed the Reach & RoHS.
Machines were packed.
