Handheld Type Cable Tie Installation Tool On Using 2.5 * 100mm Cable Ties
To install cable ties easily. When your workers are using 2.5 * 100mm cable ties to bundle products, our machine is suitable for you.
It helps you to save time, save money. Pls contact me to talk more about the machine.
SWT25100H parameter
| No. | Item | Description | Value |
| 1 | Model | SWT25100H | No |
| 2 | Size Of cable size | Width | 2.5mm |
| Length | 4inch/100mm | ||
| Thicker | 1.25mm | ||
| 3 | Operation speed | For one cable tie | 0.7S |
| 4 |
Max banding Dia.
|
For wire | Ø 17mm |
| For tube | Ø 16mm | ||
| 5 | Min banding Dia. | For tube / wire | Ø 2mm |
| 6 | The feeding hose | Length | 2m-2.5m |
| 7 | The bending force | 0-8kg | |
| 8 | Voltage | AC220V, 50 / 60Hz | |
| 9 | The gun V. | DC24V ( auto switch ) | |
| 10 | Power | 1,000W | |
| 11 | Pneumatic pressure | 5kg / cm² | |
| 12 | Warranty | 1year | |
SWT25100H details
1 . Multifuction
| No. | Item | Description |
| 1 | Feeding | Vibration feeding to the gun head |
| 2 | Bundling | Binding the goods with cable tie through the gun |
| 3 | Tempreture control | Improve the cable tie toughness when using the machine |
| 4 | Quantity of cable ties | Count the qty after the operation succeeded |
| 5 | Auto detect jam | Automatically detect the jam and deal with it |
| 6 | Using ways | Handheld type or fied type by adding a support |
2 . Using loose cable tie W2.5 * H100mm, vibration feeding and bundle in the gun head.
3 . Operation speed is about 0.7s and faster than by hand.
4 . Waste material collecting methods for choice.
5 . One machine can replace at least one worker and save labor cost.
With Swift trade terms
| Payment term | 100%TT before shipment ( negotiation available ) |
| Lead time after payment | 10 days or 15days |
| Shipping way | By sea, by air |
| Fob sea port | Shenzhen |
| Price | Fob Shenzhen / EXW |
Our Service
Inquiry. Pls contact us by email, phone, fax, Skype, whatspp, linkedin.
Videos. Wechat, Linkedin, Youtube and facebook, you can find our machine videos through searching Swift automation technology CO., LTD.
Discussions. Welcome to discuss the bundled goods, machine specifications. OEM and ODM are accepted.
Quotation is offered.
Good after - service. Pls contact us if you have any questions.
FAQ
1. Are you a factory?
Yes, we are a factory that is located in Shenzhen, China.
2. Can I use our cable ties in the machine?
Yes, it is no problem to use your cable ties in the machine. And we would make the machine according to these nylon ties.
3. Are the machines certified CE?
Yes, all machines pass CE.
4. Do you have RoHS for cable ties?
Yes, we have RoHS and Reach.
