Electric Handheld Nylon Belt Cable Tie Machine For Wires Bundle Diameter Up to 31mm
One automatic cable tie machine replaces 4-6workers, save cost and improves the bundle speed.
What should you worry about when to purchase the machine?
1. The bundle failure. That means you waste a cable tie. What should I do?
2. Cable tie jammed in the tool head or the hose. That means you would spend time to fix it.
3. How many cable ties has the tool dealt with?
4. How many cable ties are bundled unsuccessfully?
5. How about the after-sales service?
Swift handheld nylon cable tie machine advantage
1. Automatically detecting the failure. If the tool gun failed to handle the cable tie, the machine would stop immediately, and automatically deal with the failed cable tie, then automatically restart itself.
2. Automatically detecting cable tie jam. If there is any cable tie jammed in the tool gun or in the hose, the machine would stop running and automatically clean the jammed cable tie, then restart automatically.
3. The machine counts cable ties quantity only after the bundle operation succeeded.
4. With temperature controlling system. It is to improve the cable tie toughness when using the machine and cable tie under 15℃.
5. We guarantee 5million cycles maintenance free. And if the machine has anything wrong, we provide online/Skype guide.
Technical data
| Description | Automatic cable tie tool | ||
| Brand | SWIFT | ||
| Model | SWT36150H | ||
| What cable ties can be used in this machine? | Ties type | Loose cable ties | |
| Tie model | T36150 | ||
| Tie width | 3.6mm | ||
| Tie length | 150mm | ||
| Tie thickness | 1.2mm | ||
| Tensile strength | 14Kgf | ||
| Quantity per bag | 500pcs | ||
| Max bundling Dia. for wire | 3.1cm | ||
| Max bundling Dia. for tube | 3.0cm | ||
| Min bundling Dia. | 0.3cm | ||
| Bundling speed | 1.0S | ||
| Cable tie gun details | Power | DC24V auto transferred | |
| Size | L271 * W116* T74mm | ||
| Tension forces | Adjustable | ||
| Power supply | AC220V, 50/60Hz; AC110V, 50/60Hz | ||
| Pneumatic pressure | 5kg/cm² | ||
| Max Power | 1,000W | ||
| Certificates | CE, RoHS | ||
Packing details
The host machine: be packed in wooden case, size: L870 * W970 * H900mm
The vibration bowl: be packed in wooden case, size: L790 * W800 * H700mm
Payment terms
1. 70% deposit before production and 30% balance payment before ship.
2. Delivery time: normally 10-15working days.
3. Shipment ways: by sea, normally 30 -45days.
4. Sea port: Shenzhen, Shanghai or others.
5. By Express, DHL, UPS etc.
Other machines
| Automatic cable tie system, using cable tie reels | ||
| Model | SWT25100FC | SWT36200FC |
| Cable tie type | Reel cable ties | |
| Qty / reel | 5,000pcs | 4,000pcs |
| Cable tie specifications | Width 2.5mm | Width 3.6mm |
| Length 100mm | Length 200mm | |
| Head size of cable tie | L4.8 * W5.0 * H3.7mm | L6.7 * W6.6 * H4.6mm |
| Gun head size | L278 * W240 * H149mm | L299 * W240 * H149mm |
| Host machine size | L470 * W230 * H710mm | |
| Power supply | AC220V, 50 / 60Hz, plugs available | |
