Handheld Auto Bundling Machine , Nylon Tie Tool For Automatically Binding And Cutting Off

Handheld Gun Using Cable Tie Machine Automatic Bundling Up To ø 31mm



Handheld cable tie machine to bundle objects with zip ties. You only spend 1.0S finishing wrapping, tightening and cutting off cable tie. Zip tie size is W3.6 * L150mm.



Why do you choose cable tie machine?



If you use large quantity of cable ties, such as 40,000pcs per month, that means there are at least 8workers to bind cable ties by hand.



When use cable tie machine, you just need to buy two machines to do the job.



Your factory will save at least 5 or 6 workers’ labor cost.



SWT36150H advantages



1 . Automatically bind and cut off cable ties. It is no problem if you don’t want the machine to cut off cable tie. Pls inform us by email and we would modify the system program.



2 . Automatically feed cable ties through the vibration bowl. You don’t need to pick it up one by one.



3 . Automatically detect if it is successful to bundle the cable tie. Or it would stop and deal with the failed cable tie.



4 . Be comfortable to hold and operate the gun head.



5 . The tightening force is adjustable.



SWT36150H basic data



Name	Cable tie machine	Model	SWT36150H	Using type	Handheld
Cable tie type	Loose cable tie	Cable tie width	3.6mm	Cable tie length	150mm
Size of host machine	L890 * W900 * H790mm	Weight of host machine	160kg	Material	Metal
Size of gun head	L271 * W116 * H74mm	Weight of gun head	0.90kg	Certificate	CE
Electric power	AC220V, 50 / 60Hz	Power	1000W	Pneumatic pressure	5kg / cm²



SWT36150H technical specifications



Bundling Max Dia. for wire / tube	Ø31mm / Ø 30mm	Bundling Min Dia.	Ø3mm
Operation speed	1.0S	Actual pneumatic pressure	3 - 5 kg / cm²
Temperature	40℃	Qty of cable ties per time in vibration bowl	200 – 300pcs



Applications



Rail transportation sector



Electrical installation



Food industry



Wiring harness



Package



The machine would be packaged in wooden cases. One for the machine, the other one is for the vibration bowl.



Our service



Before sales service – our professional sales man will reply you in time and give you suggestions.



After sales service

1. We offer 1 year warranty and tech support forever.



2. We offer online guide on guiding you operate the machine. In China mainland, we can go to your factory and install the machine for you.



FAQ



Questions	Answers
1. What is the difference between SWIFT cable tie machine and the traditional tool?	SWIFT cable tie machine can detect whether cable ties is bundled successfully or not.
2. Are you a factory?	Yes, we are located in Shenzhen. Welcome to visit our factory.
3. What is the advantage of swift cable tie machine?	Bundle quickly, save time and cost.
4. What is your payment term?	TT transfer.



Our fairs



We attended Electronic Asia 2018 in HK on October.
