Handheld Automatic Cable Tie System Electric Zip Tie Gun For Bundle Automobile Wire Harness

Handheld Automatic Cable Tie System Electric Zip Tie Gun For Bundle Automobile Wire Harness

  • High Light

    automatic cable tie machine

    ,

    automatic zip tie machine

  • Name
    Handheld Electric Zip Tie Gun
  • Application
    Auto Bundle Big Size Products
  • Model
    SWT36200HC
  • Cable Tie Size
    3.6mm * 200mm, Reel Cable Ties
  • Cable Tie Material
    Nylon 66
  • Bundle Max Dia.
    43mm
  • Min Bundle Dia.
    20mm
  • Bundle Speed
    1.3S
  • Place of Origin
    Shenzhen, China
  • Brand Name
    SWIFT
  • Certification
    CE, Rohs
  • Model Number
    SWT36200HC
  • Minimum Order Quantity
    1pcs
  • Price
    Negotiation
  • Packaging Details
    Wooden cases
  • Delivery Time
    12 - 15days
  • Payment Terms
    T/T
  • Supply Ability
    100pcs/month

Handheld Automatic Cable Tie System Electric Zip Tie Gun For Bundle Automobile Wire Harness

Automatic Cable Tie Handheld Electric Zip Tie Gun For Bundle Automobile Wire Harness



Using automatic cable tie reel, C36200; there are 4,000pcs nylon cable ties in a reel, after running out them, pls replace a new reel.



SWT36200HC specifications





Product name Automatic cable tie tool
Model SWT36200HC
Components The host machine, handheld cable tie gun and reel cable ties
Cable ties size W3.6 * L200mm, reel cable ties
Min binding dia. 20mm
Max binding dia. for wire/tube 43mm/42mm
Operation speed 1.3S
Power 1000W
Electric power AC220V, 50/60Hz
Pneumatic pressure 5kg/cm2



Functions



1. It is smaller. And the noise is lower.



2. There is a handheld electric cable tie gun. Once push the trigger, automatic wrapping, pulling and tightening, cutting off nylon cable ties.



3. Finishing all actions takes 1.3S.



4. Using cable ties reel, 4,000pcs per reel. Pls replace a new one after running out.



5. There is a handhled cable tie gun. You could adjust the binding forces in the gun.



6. The machine could bundle different diameters objects, as long as they are less the max dia. 43mm.



7. The waste materials are collected into a box.



8. Can be applied to full automation line or can be fixed as desktop type.



Applications



1. Auto bundle automobile wire harness or oil tubes.



2. Auto bundle big size tubes or plastic pipes.



3. Auto bundle different objects(their diameters less than 43mm).



Trade term



1. 100% wire transfer before ship.



2. 12 -15 delivery days.



3. Quotation: EXW price, FOB Shenzhen



4. 1 year warranty and tech support forever.



FAQ



1. How could I adjust the binding force?



In the handheld cable tie gun, there is a knob. Pls turn it to choose the forces. The max binding force is 8kgf.



2. Must SWT36200HC use reel cable ties C36200?



Yes, it is.
