|Name:||Automatic Cable Tie Gun||Model:||SWT25080H|
|Application:||Automatic Binding Wire Harness With Nylon Cable Ties||Cable Ties Size:||W2.5 * L80mm ( Bulk Bags)|
|Bindling Dia.:||2mm - 14mm||Voltage:||AC220V, 50/60Hz, Euro Plug|
automatic wire tying tool,
wire bundling machine
80mm Cable Tie Automatic Handheld Zip Tie Tool Packing Wire Harness Fast Speed 0.7S
SWT25080H uses nylon cable ties T25080, Width2.5mm * Length80mm. The handheld cable tie tool can automatically wrap, tighten and cut off cable ties after tighten the items. It takes 0.7S to finish sigle cable tie.
1. Automatically binding wire harness with nylon cable ties. It is very fast.
2. Once touch the trigger in the zip tie tool, it would start to work.
3. The operate speed is 0.7S per cable tie.
4. Automatically detect if it is successful to bundle the cable tie. Or it would stop and deal with the failed cable tie.
5. There is a handheld cable tie gun and it is easy to hold and operate.
6. The tightening forces are adjustable.
SWT25080H zip tie tool basic data
|Name||Automatic cable tie tool||Model||SWT25080H|
|Cable ties size||W2.5 * L80mm||Cable tie model||T25080|
|Bundling Dia.||Ø2mm - Ø 30mm||Operation speed||0.7S|
|Electric power||AC220V, 50 / 60Hz||Actual pneumatic pressure||5 kg / cm²|
Rail transportation sector
The machine would be packaged in wooden cases. One for the machine, the other one is for the vibration bowl.
1. 1 year warranty and tech support forever.
2. Online guide
In Shanghai, 2019.
