Fixed Cable Tie Gun Automatic Cable Tie Tool For Wiring Harness PVC Sleeve SWT25100F
The fixed cable tie gun is havier than the handheld cable tie gun. It is usually fixed in the bench. Operater could hold the items with two hands.
SWT25100F advantages
1. Once tread the foot pedal, automatically start to wrap, pull and tighten, cut off nylon cable ties.
2. Bundling one cable tie takes about 0.8S normally.
3. 4 tension forces adjustable(2kg, 4kg,6kg and 8kg).
4. With temperature controll system. It helps to protect the toughness of nylon zip ties under 15℃. Pls set 40℃ - 45℃.
5. PLC control system and touch screen(Chinese and English languages).
6. Be suitable for the wires with PVC sleeve, or bags sealed.
7. Voltage: AC220V, 50/60Hz; Euro plug, UK plug
SWT25100F base data
| 1 | Description | Automatic cable tie tool for wire harness PVC sleeve bundle | |
| 2 | Brand | SWIFT | |
| 3 | Model | SWT25100F | |
| 4 | Cable ties details | Type | Loose nylon cable ties |
| Model | T25100 | ||
| Width | 2.5mm | ||
| Length | 100mm/4inch | ||
| Thickness | 1.1mm | ||
| Tensile strength | 8kg | ||
| Quantity/bags | 1,000pcs | ||
| 5 | Usage/per time in vibration bowl | 300pcs enough(Note, pls put some nylon cable ties before they are used up) | |
| 6 | Product Dimension | Bundle ø max. | 18mm |
| Bundle ø min. | 2mm | ||
| 7 | Bundling speed | 0.8S | |
| 8 | Cable tie gun | Power | DC48V |
| Size | L27 * W24 * T14cm | ||
| Tension forces | Adjustable | ||
| 9 | Power supply | AC220 - 240V, 50/60Hz | |
| 10 | Pneumatic pressure | 5kg/cm² | |
| 11 | Max Power | 1kw | |
| 12 | Certificates | CE and RoHS certified. | |
Applications
| Home appliance | Wirings inside fan, air conditions, fridge etc |
| Auto industry | Auto oil pipes, auto wirings on board |
| Food industry | Bags sealed, the food label fixed, crab claws bundled, oil bottles fixed |
Trade terms
1. Payment: 100%TT payment before shipment.
2. Lead time: 10 - 15working days after receive payment.
3. Shipment: By sea/express.
Packing details
| SWT25100F Packing Details | ||
| Export wooden case | 2pcs | |
| The host machine / wooden case | G.W. | 101kg |
| Packing Size | L760 * W730 * H820mm | |
| The vibration bowl / wooden case | G.W. | 68kg |
| Packing Size | L670 * W550 * H910mm | |
| Total G.W. | 169kg( estimated) | |
FAQ
1. Are you a factory?
Yes, we are a professional factory that only produces automatic cable tie tool and nylon zip ties.
2. Do I need to wrap cable ties then use the cable gun to tighten?
No, you don't. Once tread the foot pedal, the machine would do all actions including warpping, pulling and tightening, cutting.
3. Must I use your cable ties, such as T25100?
Yes, we usually ask clients to use T25100. The machine asks high quality cable ties. Our factory also produces nylon zip ties for tool using.
Our products are sold all over the world, you can rest assured.
